Vecchia

Porcelain Tile | Floor & Wall Tile

4 Colors  |  2 Finishes  |  12 Options

Downloadable Documents

Vecchia_Spec Sheet_110625.pdf
Ghiaccio
Cenere
Dorato
Ossidiana

Details

Performance Test

Method

Result

Packing

Pcs†

SF†

Lbs†

INSTALLATION INSTRUCTIONS
• Install on flat, clean, and cured substrates.
• Use polymer-modified thin-set (ANSI A118.4 / A118.15).
• Apply adhesive to both tile and substrate for full coverage.
• Maintain minimum 2 mm grout joint (rectified).
• Use colored or epoxy grout, match color to tile.
• Follow industry standards for expansion joints.
• Protect surface during and after installation.

Product Attributes

Available Shapes & Sizes

24" x 48" | 48" x 48" | 48" x 110"

12” x 12” Mosaic

See Spec Sheet For Corner Pieces & Baseboard Sizes
Water Absorption
ISO 10545-3
Complies with the standards
Abrasion / Scratch Resistance
ISO 10545-7
As stated by the Company
Thermal Shock Resistance
Resistant
Thermal Linear Expansion Coefficient
≤ 7 x10-6 C-1
Resistance to Cold/Frost
ISO 10545-12
Resistant
Resistance to Chemicals
ISO 10545-13
Resistant
Resistance to Staining
ISO 10545-14
Resistant
See Spec Sheet
48” x 110”
36.17 SF
48” x 48”
2
31 SF
134.33 Lbs
24” x 48”
2
15.50 SF
65.40 Lbs
12” x 12” Mosaic
11
10.66 SF
43 Lbs
1/4” x 48” Triangular Corner Cover
6
0.62 SF
1/2” x 48” Triangular Corner Cover
6
0.01 SF
1/4” x 1/4” Angled Triangular Corner
6
1/2” x 1/2” Angled Triangular Corner
8
5.60 SF
15.28 Lbs
2 1/2” x 48” Baseboard
9
7.32 SF
31.30 Lbs
13” x 48” x 1 1/4”h Step
2
8.52 SF
46.30 Lbs
13” x 48” x 1 1/4”h Left Step
1
4.26 SF
25.15 Lbs
13” x 48” x 1 1/4”h Right Step
1
4.26 SF
23.15 Lbs

† All values are per box.
